ICM32060 - AH-1G Cobra (Early Production), U.S. Attack Helicopter

In March 1965, manufacturer Bell began development of a close air support combat helicopter based on the Model 204 (UH-1B/-1C Iroquois). The plan was to provide the U.S. Army with a test helicopter that would combine a new narrow fuselage with a small cross-section and tandem seating arrangement, power plant, main rotor and transmission of the UH-1C helicopter. Designated Model 209, it was tested beginning in December of the same year, with orders for two pre-production models and 110 production units following in April 1966.

Eventually designated the AH-1G and named the Huey Cobra, it began supplying to the U.S. Army in June 1967 and was used in combat operations in Vietnam in September. 1,127 AH-1Gs were delivered to the U.S. Army, including the TH-1G dual-control training helicopters.

The serial AH-1G helicopter, which became the base for further modifications, had a single-rotor design with a tail rotor, one GTE and a ski landing gear. The fuselage was an all-metal, half-monocoque type. The cockpit is two-seat, with the shooter and pilot seats located one behind the other. The floor level in the gunner’s compartment (located in front of the pilot) is 0.25 m lower. The lantern with flat glasses minimises glare and increases the space above the pilot’s head, the helicopter is equipped with an advanced autonomous system of emergency window and door dropping. Lightweight steel armour is used to protect the crew and the most critical areas of the structure and components from ground fire. Tail boom structure is reinforced to withstand 23-mm projectiles. The helicopter airframe is painted to reduce the visual and infrared signature.

Model Features

• Accurate copy of the prototype
• The kit includes AH-1G Cobra helicopter (early production) with XM158, XM157, XM-200, and XM-18 rockets
• Four version decal sheet is included

Markings Available

• AH-1G Cobra (early production), 5728 /47 “Blue Max" 2nd Battalion, 20th Artillery Regiment (Aerial Rocket Artillery, ARA)
• АН-1 G Cobra (early production), 66-15252 / 15 presumably Cobra NETT
• АН-1 G Cobra (early production), 66-15310, В Battery, 2nd Battalion, 20th Artillery Regiment (Aerial Rocket Artillery, ARA), 1st Cavalry Division (Airmobile). Originally assigned to the Cobra New Equipment Training Team (Cobra NETT), 1967
• АН-1 G Cobra (early production), 67-157621 Executioner, 235th AC, Capt Lou Bouault (aircraft commander), Daub Ting, November 1969

Model Information

• Scale: 1:32
• Number of Parts: 226 pieces
• Length: 422 mm
• Width: 106 mm
• Includes detailed assembly instructions
• Highly detailed sprues with high accuracy made from quality plastic
• Box size: 410 x 260 x 100 mm
